Power Ethernet Adapter – USB-C

Specifications

• Dimensions: 3.52” (8.94 cm) L x 3.25” (8.3 cm) W x 1.46” (3.71 cm) H
• Weight: 0.86 lbs/390.09 g – Aviation Grade Aluminum Housing (6061-T6)
• DZUS Mounted or Sidewall with Hardware
• Four (4) each # 4 – 40
• Inputs: 28 VDC @ 1.7 Amp Max
• Outputs: Power Delivery (PD) – 5.0VDC – 20VDC @ 3.0AMP MAX (60W) and Ethernet

Mating Connectors – J1 (Input)

M24308/2-1F

• Pin 1 – Power 28VDC,
• Pin 2 – Ground
• Pin 3 – Chassis
• Pin 4 – Remote Disable
• Pin 5 – Ethernet
• Pin 6 – Ethernet
• Pin 7 – Ethernet

Part Number: 213013-26

Ethernet connection, power delivery (PD) charging connection, secure data transfer using USB-C.

Works with all Tablets that have USB-C ports

Mating Connectors – J2 (Output)

USB-C Proprietary Connection
